BATTERY AUTOMATIC CARE SYSTEM
The integrated batteries incorporate a high performance BMS (Battery Management System) offering a very controlled consumption to increase range and lengthening the useful life of the battery. In the case of not being used for long periods, the deep sleep mode is automatically activated and allows a battery with just 10% of its charge can be recharged up to 400 days later.
The battery is now housed in an aluminum shell that aids in heat management while also blending into the frame. The battery can be charged directly from a port integrated in the frame or from the battery itself, allowing a rapid charge to 80% of the capacity in 2 hours, a full charge in 3 hours.
HIGH EFFICIENCY REAR MOTOR
The 500W motor has been tuned to provide more power with peak output of 740W. The new motor includes a thru-axle design that facilitates easier removal and installation of rear wheel. A new external motor wire catch eases the wheel change process.
REMOVABLE LCD DISPLAY
The side mounted display has been updated with new easier to use buttons and improved LCD display. The Pro models come with the new, large center mount display.
• Range information, battery capacity in %, time, speed, total or journey distance.
• Selection of assistance mode (eco, standard, sport and boost) or no assist/throttle only(limited models)
• Switch lights on/off.
• Choose kilometers or miles.
|Frame||Sport Alloy 28" internal cable routing|
|Fork||SR Suntour NEX HLO|
|Rims/Wheels||Alloy Double Wall/Alex DM18|
|Hubs||Shimano XT HB-M8000, QR, Shimano XT FH-M8000, QR|
|Tires||Schwalbe Big Apple 28"x2"|
|Crankset||Shimano Acera 48/38/28T|
|Bottom Bracket||Cartridge bearing|
|Front Derailleur||Shimano Ultegra FD-R8000-F|
|Rear Derailleur||Shimano Alivio 9sp|
|Rear Cogs||Shimano HG20 9SP (11-34T)|
|Handlebars||Emotion Cross Alloy|
|Brakes||FRONT Tektro E-Comp 180mm REAR Tektro E-Comp 160mm|
|Seat Post||Alloy 31.6|
|Seat Binder||Quick Release|
|Accessories & Extras||Kickstand, Chain Protector|
|Electric||32km/hr LCD Emotion, MOTOR 500W Thru Axle, Battery 500Wh, System Evo|
* Subject to change without notice.
