Rocky Mountain Pipeline Carbon 50

Rocky Mountain Pipeline Carbon 50
$4,237.49
$5,649.99
Color:
Blue/Red
Size:
Large
Please select options
This item is not permitted to be shipped, however it can be purchased online and picked up at your convenience.

Details

The Rocky Mountain Pipeline combines the confidence of plus-sized tires in raw, technical terrain with an aggressive trail chassis. RM pushed the rear travel to 140mm, increased stiffness, and adjusted the suspension kinematics for more efficient pedaling and better small-bump sensitivity. Available in both carbon and alloy models, the Pipeline plows through greasy roots and square-edged chunder with authority, while providing near limitless traction on rocky, slippery climbs. The Pipeline Carbon 50 version brings together a burly Smoothwall carbon frame, 140mm Fox 34 fork, DPS EVOL shock, and 27.5 x 2.8-inch Maxxis tires on Race Face AR 35 rims. That’s a combination that sets you up for success running steep, technical trail or shredding smooth-berm park runs. SRAM serves you with a GX Eagle 1x12 drivetrain that offers a massive range of gearing with smooth shifting to get you anywhere you want to go, while Shimano SLX brakes rein it in with sure-stopping power that won’t fade away. Rocky Mountain cockpit components and Fox Transfer dropper post round out the spec to make an almost too-fun trail bike that leaves behind big smiles everywhere it goes.

The RIDE-9 adjustment system allows riders to quickly fine-tune their geometry and suspension with a pair of Allen keys. Nine configurations are possible thanks to two interlocking chips. Position 1 geometry configuration shown below.

Rocky Mountain Pipeline geometry chart

Specs

Frame SMOOTHWALL Carbon. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. RIDE-9 Adjustable Geometry + Suspension Rate. FORM Alloy Rear Triangle
Fork Fox 34 Float Performance 140mm
Headset FSA Orbit NO.57E Extend-o-matic
Rear Shock Fox Float DPS EVOL Performance
Axles Front: 110 x 15mm
Rear: 148 x 12mm
Rims/Wheels Race Face AR 35
Hubs Rocky Mountain Sealed Boost 15mm / DT Swiss 370 Boost 148mm
Spokes WTB 1.8-1.6
Tires Front: Maxxis DHF EXO Tubeless Ready 27.5 x 2.8
Rear: Maxxis DHR EXO Tubeless Ready 27.5 x 2.8
Crankset SRAM Stylo 6k Eagle
Chainrings 32T
Bottom Bracket SRAM BB92 DUB
Chain SRAM NX Eagle
Rear Derailleur SRAM GX Eagle
Cassette/Rear Cogs SRAM PG-1230 11-50T
Shifters SRAM GX Eagle
Handlebars Rocky Mountain AM 760mm
Tape/Grips Rocky Mountain Lock On Light
Stem Rocky Mountain AM
Brakes Shimano SLX
Saddle WTB Volt Race
Seat Post Fox Transfer Performance Elite 30.9mm

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Blue/Red / Large 770416242522 CRS941181 23167
